This is a WC67K Hydraulic Press Brake Machine
Specification:
Voltage : 280V
Max. Bending Thickness : 2 mm
Max. Bending Width : 1600 mm
Frequency : 50 HZ
Power Consumption : 4 kw
- CNC Controller: DELEM DA41S, Holland
- European standard Punch & Dies
- Main motor: Siemens Germany
- Oil pump: Sunny, America
- Hydraulic Valve: Bosch Rexroth, Germany
- Foot Pedal: Kacon, Korea
- Electric: Schneider, France
- Ball screw & linear guide
- Photoelectric Proximity Switch
- Mechanical quick clamps
- Servo motors
Features
- Dutch Delem DA41S CNC controller.
- Servo drive and control positioning of 2axes(X, Y).
- Linear guide rail and ball screw accuracy of 0.01mm(HIWIN,TAIWAN).
- Steel mono-block construction.
- Adjustable stop fingers.
- Standard electrics from Schneider,France.
- Standard oil tube connectors from EMB Germany.
- Standard valves and oil pump from Bosch Rexroth Germany.
- Standard main motro from Siemens Germany
- Hydraulic and electrical overload protection
- Light guards ensure the safety of operators during operation
It is in a good working condition.
No pending loan against the machine.
It has been Recently serviced.
